Table

Tables display read-only tabular data with pagination. Use F7/F8 to page through large datasets.

Basic Usage

from ux3270.dialog import Table

table = Table("INVENTORY LIST", panel_id="INV01")
table.add_column("ID")
table.add_column("Name")
table.add_column("Qty", align="right")
table.add_column("Status")

table.add_row("001", "Widget A", "100", "Active")
table.add_row("002", "Widget B", "50", "Active")
table.add_row("003", "Gadget C", "0", "Out of Stock")

table.show()

Column Alignment

table.add_column("Amount", align="right")  # Right-align numbers
table.add_column("Name", align="left")     # Left-align text (default)

Column Width

By default, columns auto-size to fit content. You can specify a fixed width:

table.add_column("Description", width=30)

Header Fields

Add input fields above the table for filtering or positioning:

table.add_header_field("Position to", length=20)
result = table.show()
position = result["Position to"] if result else ""

Pagination

Tables automatically paginate based on terminal height:

• F7 or Page Up - Previous page
• F8 or Page Down - Next page

The row count message shows current position: ROW 1 TO 10 OF 50

Auto-Truncation

If content is too wide for the terminal, long columns are automatically truncated with a > indicator:

ID    Name              Description
---   ---------------   ---------------------------
001   Widget A          This is a very long descrip>
002   Widget B          Short desc

API Reference

ux3270.dialog.Table

IBM 3270-style table/list display with pagination.

Displays tabular data with column headers following CUA conventions: - Panel ID at top-left, title centered - Optional header fields (e.g., "Position to" filter) - Column headers in intensified text - Data rows in default (green) color - Row count/pagination info on message line - F7/F8 for page up/down (CUA standard) - Function keys at bottom

The dialog builds a Screen definition and hands control to Screen for all rendering and input handling.

__init__(title='', panel_id='', instruction='')

Initialize a table.

Parameters:

Name	Type	Description	Default
title	str	Table title (displayed in uppercase per IBM convention)	''
panel_id	str	Optional panel identifier (shown at top-left per CUA)	''
instruction	str	Optional instruction text	''

add_column(name, width=None, align='left')

Add a column definition.

Parameters:

Name	Type	Description	Default
name	str	Column name (used as header)	required
width	Optional[int]	Display width (None = auto-calculate from content)	None
align	Literal['left', 'right']	Text alignment ("left" or "right")	'left'

Returns:

Type	Description
Table	Self for method chaining

add_row(*values)

Add a row to the table.

Parameters:

Name	Type	Description	Default
values		Column values for the row	()

Returns:

Type	Description
Table	Self for method chaining

add_header_field(label, length=10, default='', field_type=FieldType.TEXT)

Add a header field (e.g., "Position to" filter).

Parameters:

Name	Type	Description	Default
label	str	Field label	required
length	int	Field length	10
default	str	Default value	''
field_type	FieldType	Field type	TEXT

Returns:

Type	Description
Table	Self for method chaining

get_header_values()

Get current header field values.

show()

Display the table with pagination and wait for user input.

Returns:

Type	Description
Optional[Dict[str, str]]	Dictionary of header field values, or None if no header fields.
